Blue Fiber
Everfoton's Blue Fiber made of special materials is designed to meet the processing and application requirements of blue lasers. With high hydroxyl content and a pure silica structure, the fiber has excellent properties in fiber attenuation and laser damage threshold,meeting the application requirements of certain high-power CW and pulsed lasers. Blue fibers with different geometric sizes and NAs are customized according to different customer application requirements.
Low loss for blue band, suitable for medium and high power energy transmission
High laser damage threshold for blue band,stability of long-term operation
Customized geometric sizes and NAs
Customized coating materials
027-65271788
sales@everfoton.com
Applications
- Blue lasers
- Laser display
- Laser illumination
- Laser detection
- Medical
- Scientific research
Specifications
| Fiber Type |
UV 105/125 -22/300E（DC） |
UV135/160 -22/320(DC) |
UV200/220 -22/320(DC) |
UV 300/330-22/720E(DC) | UV 400/440-22/880E(DC) |
UV600/660 -22/1100E（DC） |
UV910/1000 -22/1300(DC) |
||
| Part No. | UV2140-A | UV2110-B | UV2110-C | UV2140-C | UV2140-D |
UV2140-B |
UV2110-A |
||
| Optical Properties | |||||||||
| Operating Wavelength (nm) | 300~800 | ||||||||
| NA | 0.22 ± 0.02 | 0.22 ± 0.02 | 0.22 ± 0.02 | 0.22±0.02 | 0.22±0.02 | 0.22 ± 0.02 | 0.22 ± 0.02 | ||
| Cladding NA | ≥0.37 | ≥0.37 | ≥0.37 | ≥0.37 | ≥0.37 | ≥0.37 | ≥0.37 | ||
| Fiber Refractive Index Structure | Step Index | ||||||||
| Gemetriacal Properties | |||||||||
| Core Diameter (µm) |
105.0±3.0 |
135.0±4.0 |
200.0±3.0 |
300.0±6.0 | 400.0±8.0 |
600.0±6.0 |
910.0±10.0 |
||
| Cladding Diameter (µm) |
125.0±1.0 |
160.0±5.0 |
220.0±5.0 |
330.0±7.0 | 440.0±9.0 |
660.0±8.0 |
1000.0±15.0 | ||
| Core/Cladding Concentricity (µm) | ≤ 1.0 | ≤ 1.0 | ≤ 1.0 | ≤2.0 | ≤4.0 | ≤ 6.0 | ≤ 15.0 | ||
| Coating Diameter (µm) |
300.0±30.0 |
320.0±20.0 |
320.0±20.0 |
720.0±35.0 | 880.0±45.0 |
1100.0±40.0 |
1350.0±50.0 |
||
| Material Properties | |||||||||
| Core Material | High-OH Pure Quartz | ||||||||
| Cladding Material | Fluorine-doped Quartz | ||||||||
| inner Coating Material | Low Refractive Index Coating | ||||||||
| Outer Coating Material | ETFE | Acrylic Resin | Acrylic Resin | ETFE | ETFE | ETFE | Acrylic Resin | ||
| Operating Temperature (℃) | -40 ～ +85 | -40 ～ +85 | -40 ～ +85 | -40～+85 | -40～+85 | -40 ～ +85 | -40 ～ +85 | ||
| Proof Test (kpsi) | ≥ 100 | ≥ 100 | ≥ 100 | ≥100 | ≥100 | ≥ 100 | ≥ 75 | ||
